Morimoto | BigBanger HXB LED Pod (Spot / White / Each)

Morimoto – BigBanger HXB LED Pod (Spot / White / Each)

Description

The Morimoto BAF122 BigBanger HXB Spot White is the most powerful LED pod in the BigBanger lineup. Designed and torture-tested in the USA, it uses 7 Osram HX Boost LEDs (5700K) to produce 564,000cd (post-warm-up) and penetrate up to 800 meters. The HXB Spot beam is purpose-built for fast-paced night driving on the trail. Amber backlight (12 CREE XP-E2 PC Amber) runs brightly during the day and automatically dims 90% at night to prevent glare for oncoming traffic. Built around a copper DTP (direct thermal path) PCB, electroplated powdercoated die-cast aluminum shell, and IP69K-rated gasket system with integrated DT connector and breather valves. Sold individually. Compatible for building modular BangerBar light bars.

Specifications

• Brand: Morimoto
• Part Number: BAF122
• Intensity: 564,000cd (Post Warm-Up)
• LED Source: 7x Osram HX Boost (5700K) + 12x CREE XP-E2 PC Amber (Backlight)
• Peak Luminosity: 7,000lm (raw)
• Power: 77.0W (Stabilized), 30W (Backlight), 8W (Dim Backlight)
• Current (@ 13.5V DC): 5.55A (Stabilized), 8.15A (Startup)
• Input Voltage: 9–18V DC
• Input: Integrated Deutsch DT 4-Pin
• Dimensions: 154 x 136.7 x 76.1mm
• Material: Makrolon LED PC (Lens) / Powdercoated Die-Cast Aluminum (Housing)
• Rating: IP69K
• Warranty: Lifetime Limited
• Condition: New – Sold and shipped by GBP Performance
