Morimoto | BigBanger NCS LED Pod (Spot / White / Each)

Morimoto – BigBanger NCS LED Pod (Spot / White / Each)

Description

The Morimoto BAF118 BigBanger NCS Spot White is a high-intensity off-road LED pod sold individually. 7x Nichia NCSW131F LEDs produce 495,000cd (post warm-up) in a tightly focused spot pattern (5° hot spot surrounded by 14H×4C° flood) for maximum long-range visibility. Integrated Cree XP-E2 amber backlight (dual-intensity: full brightness by day, auto-dim 90% at night to avoid glare). Can be run solo or linked into a custom light bar with BangerBar connectors. Copper DTP PCB, electroplated powder-coated aluminum housing, IP69K. Universal bottom-mount U-bracket included. Lifetime warranty.

Specifications

• Brand: Morimoto
• Part Number: BAF118
• Intensity: 495,000cd (post warm-up)
• Main LED: 7x Nichia NCSW131F
• Backlight: 12x CREE XP-E2 PC Amber
• Power: 36.5W (stabilized) / 30W (backlight) / 8W (dim backlight)
• Peak Luminosity (raw): 3,150lm
• Input Voltage: 9–18V DC
• Input: Integrated Deutsch DT 4-Pin
• Dimensions: 154mm W, 136.7mm H (153.5mm w/ bracket), 76.1mm D
• Material: Makrolon LED PC (Lens) / Powdercoated Die Cast Aluminum (Housing)
• IP Rating: IP69K
• Sold: Individually (1 pod + 1 universal U-bracket)
• Warranty: Lifetime Limited
• Condition: New – Sold and shipped by GBP Performance
