Morimoto | 4Banger Universal Kit (NCS / Spot / White)

Morimoto – Off-Road LED Pods

Description

The Morimoto 4Banger Universal Kit (SKU BAF001UNL) includes a pair of NCS Spot white LED pods, universal tube/bar mounts (3/4 in to 2 in diameter), angle-adjustable U-brackets, and a universal switched relay harness. Designed, engineered, and tested in the USA, the 4Banger is approximately 30% smaller than comparable alternatives. The NCS Spot beam features a highly focused 5-degree hot spot surrounded by a 14H x 4C degree flood beam for long-range visibility. Die-cast aluminum housing with DTP copper PCB for heat management, IP69K-rated sealing. Compliant with SAE J581 for auxiliary high beam (Spot). Bolt-on installation.

Specifications

• Brand: Morimoto
• SKU: BAF001UNL
• Category: Off-Road LED Pods – Universal Kit
• Beam Pattern: NCS Spot – White
• Intensity (White): 105,000 Cd (Post Warm-Up) / 1,005 lux @ 10m
• Power: 15.6W (stabilized) – 1.5A @ 13.5V DC
• Peak Luminosity (raw): 1,350 lm
• Dimensions: 82mm W x 67mm H x 60mm D
• Light Source: 3x Nichia NCSY131F or NCSW131F
• Weather Rating: IP69K
• Kit Contents: 2 NCS pods, universal tube mounts, U-brackets, relay harness
• Condition: New
• Warranty: Lifetime Limited
• Sold and shipped by GBP Performance
