Edelbrock | Carburetor - Chevrolet / Dodge / Ford / Plymouth / Pontiac 1971-1981

Edelbrock – AVS2 Series Carburetor

Description

The Edelbrock AVS2 Series carburetor part #1905 650 CFM is the next generation in Edelbrock carburetors, designed and calibrated for optimum street performance in small-block and some big-block engines. Features annular flow primary boosters with a new calibration for improved off-idle and cruising performance. Eight equally spaced orifices per booster improve fuel metering from idle to main circuit. Includes both timed and full vacuum ports for ignition advance. Factory calibration: primary jets .101, secondary jets .098, rods .070 x .037, orange spring (5" Hg). Matches Performer, Performer EPS, RPM Air-Gap, Performer RPM, Torker II manifolds. Black-finish version: order #19053.

Specifications

• Brand: Edelbrock
• Part #: 1905
• Type: AVS2 Series Carburetor
• Flow Rating: 650 CFM
• Flange: Square
• Choke: Electric
• EGR Port: No
• Finish: Satin
• Material: Aluminum
• Body Height: 3.25 in.
• Primary/Secondary Jets: .101 / .098 in.
• Primary Metering Rod: .070 x .037 in.
• Annular booster
• Gaskets Included: Yes (See Application Section)
• Condition: New – Sold and shipped by GBP Performance
