ICON Alloys | 2023 Toyota Sequoia, 3-4.5in Lift, Stage 7 Suspension System, Billet - Sequoia 3.4T 2023-2025

Icon Vehicle Dynamics – Stage 7 Billet UCA Suspension System Toyota Sequoia

Description

The ICON Vehicle Dynamics Stage 7 Billet suspension system (ref. K53237) is designed specifically for the Toyota Sequoia V6 3.4T. Building upon the Stage 6 system, this upgrade replaces the rear shocks with 2.5 Aluminum Series remote reservoir versions for significantly increased rear shock performance and heat dissipation. The 2.5 Series front coilovers with remote reservoirs deliver superior damping, with adjustable front lift from 3 to 4.5 in. Billet aluminum UCAs provide strength, durability, and on-vehicle caster/camber adjustment with 90° articulation (Delta Joint Pro, US Pat. 10,731,700). Dual-rate rear coil springs provide 3 in. of rear lift. Front sway bar drop kit included. Tire fitment up to 35 in. All ICON shocks are fully rebuildable. (See Application Section)

Specifications

• Reference: K53237
• Manufacturer: Icon Vehicle Dynamics
• Compatibility: Toyota Sequoia V6 3.4T (see Application)
• Front lift range: 3–4.5 in.
• Rear lift: 3 in. (dual-rate coil springs)
• 2.5 Series front coilovers with remote reservoirs – superior damping, improved cooling
• Billet aluminum UCAs – caster/camber adjustment, 90° articulation (Delta Joint Pro, US Pat. 10,731,700)
• Front sway bar drop brackets included
• Dual-rate rear coil springs – 3 in. rear lift
• 2.5 Aluminum Series rear remote reservoir shocks – increased heat dissipation
• Full wheel travel without overstressing OE components
• Tire fitment up to 35 in.
• Condition: New
• Sold and shipped by GBP Performance
