ICON | 24 LAND CRUISER 250 SERIES 1.25-3in LIFT STAGE 1 SUSPENSION SYSTEM - Land Cruiser 2.4T 2024-2025

ICON Vehicle Dynamics – Suspension System

Description

The ICON Vehicle Dynamics Stage 1 suspension system (SKU K53361) is designed for the Toyota Land Cruiser 250 Series 2.4T. Vehicle-specific tuned 2.5in internal reservoir coilovers pair with ICON-engineered coil springs for superior ride feel throughout the travel range. Front lift is adjustable from 1.25 to 3in over stock. Front differential drop brackets and specially designed coilover lengths maximize front suspension travel and prevent CV bind. Dual-rate progressive rear coil springs deliver on-road comfort and off-road bottoming resistance with 2in of rear lift. ICON 2.0 Aluminum Series internal reservoir rear shocks ensure optimal front-to-rear performance balance. Passive suspension. Note: ICON Delta Joint Pro UCAs are recommended to maintain proper wheel alignment above 2in of lift.

Specifications

• Brand/Manufacturer: ICON Vehicle Dynamics
• SKU/Reference: K53361
• Front Lift: 1.25 to 3 in
• Rear Lift: 2 in
• Front Shock Diameter: 2.5 in
• Rear Shock Diameter: 2.0 in (Aluminum Series)
• Reservoir Style: Internal (front and rear)
• Suspension Type: Passive (non-adjustable)
• Rear Spring Rate Type: Progressive Dual Rate
• Materials: 6061 aircraft-grade aluminum, CAD plated corrosion resistant
• Compatibility: Toyota Land Cruiser 250 L4 2.4T (See Application Section)
• Recommended Tires: 33" x 11.50" (fender trimming may be required for larger sizes)
• Condition: New
• Sold and shipped by GBP Performance
