ICON | 1.25-3" STAGE 2 SUSPENSION SYSTEM TUBULAR OVERLAND REAR COILS - Tacoma 2.4T 2024-2025

ICON Vehicle Dynamics – Stage 2 Tubular Overland Rear Coils Suspension System

Description

The ICON K53292TX Stage 2 suspension system is designed for the Toyota Tacoma 2.4T and provides 1.25-3" adjustable front lift via 2.5 Series internal reservoir coilovers. Tubular upper control arms with Delta Joint PRO correct front-end geometry and allow maximum travel without bind. Front differential drop brackets, polyurethane differential mounting bushings, and dual-rate progressive Overland rear coil springs complete the system for superior on- and off-road performance. Rear 2.0 Aluminum Series internal reservoir shocks included. CNC machined 6061 aluminum components.

Specifications

• Brand: ICON Vehicle Dynamics
• Part Number: K53292TX
• Compatibility: Toyota Tacoma 2.4T 4WD (See Application Section)
• Front lift: 1.25-3" adjustable
• Rear lift: ~0.5" (with ~600 lbs cargo)
• Front coilovers: 2.5 Series internal reservoir, 2.5" body, 7/8" shaft
• Rear shocks: 2.0 Aluminum Series internal reservoir, 5/8" shaft
• Tubular UCAs with Delta Joint PRO (90° articulation, rebuildable)
• Dual-rate progressive Overland rear coil springs
• Front differential drop brackets included
• Polyurethane differential mounting bushings included
• Condition: New
• Sold and shipped by GBP Performance
