ICON | 1.25-3" STAGE 7 SUSPENSION SYSTEM BILLET WITH TRIPLE RATE SPRING - Tacoma 2.4T 2024-2025

ICON Vehicle Dynamics – Stage 7 Billet Triple Rate Spring Suspension System

Description

The ICON K53297S Stage 7 suspension system for the Toyota Tacoma 2.4T is identical to the K53297 but adds triple-rate progressive rear coil springs for ~0.5" of rear lift. It features 2.5 Series remote reservoir front coilovers (1.25-3" adjustable lift), billet 6061 aluminum UCAs with Delta Joint PRO and on-vehicle camber/caster adjustment, 2.5 Aluminum Series remote reservoir rear shocks (7/8" shaft), and billet rear lower links with on-vehicle pinion angle adjustment. Front differential drop brackets and polyurethane differential mounting bushings are included.

Specifications

• Brand: ICON Vehicle Dynamics
• Part Number: K53297S
• Compatibility: Toyota Tacoma 2.4T 4WD (See Application Section)
• Front lift: 1.25-3" adjustable
• Rear lift: ~0.5"
• Front coilovers: 2.5 Series remote reservoir, 2.5" body, 7/8" shaft
• Rear shocks: 2.5 Aluminum Series remote reservoir, 7/8" shaft
• Triple-rate progressive rear coil springs included
• Billet 6061 aluminum UCAs with Delta Joint PRO (90° articulation, rebuildable)
• On-vehicle camber and caster adjustment via double adjuster sleeve
• Billet rear lower links with on-vehicle pinion angle adjustment
• Condition: New
• Sold and shipped by GBP Performance
