Fabtech | Lift Kit-Suspension - Silverado / Sierra 1500 2014-2018

Fabtech – 4 in. Budget Lift System (Magneride)

Description

The Fabtech K1091 Budget Lift System is specifically designed for Chevrolet Silverado and GMC Sierra 1500 trucks equipped with factory Magneride suspension. This system utilizes the factory front coil springs with a steel upper spacer to achieve 4 in. of lift. Radius Arm drop brackets retain the factory arms with the correct caster setting for the increased ride height. The Trac Bar relocation bracket is designed to center the axle under the vehicle while remaining compatible with the factory Pitman Arm, eliminating the need for replacement and reducing cost and installation time. Rear lift is accomplished with lift blocks and extended length U-bolts. Compatible with both 4WD and RWD configurations.

Specifications

• Brand: Fabtech
• SKU: K1091
• Type: Budget Lift System (no shocks included)
• Lift Height: 4 in.
• Compatibility: Chevrolet Silverado / GMC Sierra 1500 with factory Magneride suspension (See Application Section)
• Includes: Steel front upper spacers, Radius Arm drop brackets, Trac Bar relocation bracket, rear lift blocks, extended length U-bolts, all required hardware
• Compatible with factory Pitman Arm (no replacement needed)
• Retains factory front coil springs
• Correct caster setting maintained
• Configurations: 4WD and RWD
• Installation: Bolt-on
• Condition: New
• Sold and shipped by GBP Performance
