JE Pistons | Piston Set, 2618, Inv Dome/Dish, 3.524 Bore, 1.336 CD, 0.827 Pin, Set of 4.

JE Pistons - Engine Piston Set

Description

JE Pistons is the leader in forged racing pistons. With 70-plus years of experience, in-house forging, and industry-leading technology, JE Pistons are designed to perform at the top levels of all forms of motorsports.

Characteristics

• Cylinder Head: KA24DE
• Add-On: JG1001-3524
• Add-On: 827-2250-15-51C
• Add-On: 827-063-MW
• Bore Diameter: 89.50 MM
• Compression Height: 1.336
• Piston Volume: -22 CCM
• Piston Avg Wt: 355 GR
• Piston Material: 2618
• Forging Type: Round
• Piston Head Type: Dish
• Ringset Included: Yes
• Top Compression Ring Thickness: 0.04
• Second Compression Ring Thickness: 0.048
• Oil Ring Thickness: 0.111
• Piston Pin Outside Diameter: 0.827 IN
• Piston Pin Length: 2.250 IN
• Piston Pin Material: 5115
• Piston Pin Wall Thickness: 0.150 IN
• Product Type: Piston Kits
